You are here: Home : Features : Mayka V8

Features

File Format



    PRO     ADVANCE   EXPERT
  • STEP and IGES CAD Files     NEW
 X X X
  • STL, 3DS, DXF, AI, EPS
 X X X
  • Low-relief Type 3 (vna), Color & greyscale bitmpas: GIF, JPG, BMP
 X X X
  • Mayka V7 Import & Export of scenes (from version 7.0.111+)
 X X X
  • ISO G-code, APT toolpath export: over 200 post processors available
 X X X

Milling preparation



  PRO    ADVANCE   EXPERT
  • Manual object nesting & transformation tool
 X X X
  • Automatic object nesting in a blank     NEW
     X
  • 2-sided milling management (facing, location drilling & profiling block)
 X X X
  • Attachment creation
 X X X
  • Circles recognition from contours and separation by diameters
 x x x
  • Contour extraction from model
     x
  • Model splitting by plane, zone and slicing
     x
  • Mesh simplification, model hole filling, fill a contour with mesh
     x
  • Contour extrusion to create mesh     NEW
     x
  • Merge/ separate surfaces from model
     x
  • Incline a model according to a reference facet
     x
  • Low-relief offset, resizing and sub sampling
 x  x x
  • Low-relief projection & mapping onto models
 x x x
  • Creation of punch & stamp dies from a relief grid
     x

2D Milling



    PRO     ADVANCE   EXPERT
  • Contouring, pocketing and sweeping
 X X X
  • 2D contours engraved on 3D models (3D engraving)
 X X X
  • Raised angle milling/ engraving feature
 X X X

3-axis Milling



  PRO  ADVANCE   EXPERT
  • Redefined Z constant (waterline)     NEW
 X X X
  • Optimized sweeping     NEW
 X X X
  • Profiling
 X X X
  • Horizontal faces milling
 x x x
  • Surfacing
 x x x
  • Plunge roughing
 x x x
  • 3-axis drilling
 x x x
  • Remachining     NEW
   x x
  • Offset finishing     NEW
   x x
  • Attachment reduction     NEW
   x
  • Core drilling/ Slicing
     Optional

4-axis Milling



  PRO  ADVANCE   EXPERT
  • 4-axis indexed with same features as for 3-axis
 X X X
  • Continuous 5-axis with spherical methods
 X X X
  • Inside milling (for mold and jewel)
 X X X
  • Rolling up of toolpath on a cylinder     NEW
 x x x
  • Rolling up of toolpath around a model     NEW
   x x

5-axis Milling



  PRO  ADVANCE   EXPERT
  • 5-axis indexed with same features as for 3 & 4-axis
   X X
  • Continuous 5-axis with spherical methods
   X X
  • 5-axis drilling
   X X
  • Strategy orientation according to model region     NEW
   x x
  • Toolpath trimming to a block
   x x
  • Thermoforming trimming module for 5-axis     NEW
   Optional Optional

More Milling Tools



  PRO  ADVANCE   EXPERT
  • Collision checking between tool holder & model
 X X X
  • Collision checking between tool shoulder & model
 X X X
  • Remachining limited to the block     NEW
 X X X
  • Computation of necessary tool length
 x x x
  • Tool plunge entry: direct, with pecking, along a ramp
 x x x
  • Display of undercuts and horizontal faces
  x x  x
  • Display of residual material during roughing
 x x x
  • Display of non milled surfaces after finishing
 x x x
  • NC file transfer through COM/ serial port and installed printer drivers
 x x x
  • User tool library/ Multiple core batch computation of toolpaths
 x x x

Mayka V8

The new version of our long-time developped CAM software is now available. It will be the perfect tool to team up with your CNC machine to achieve great results.
